Bacterial/Viral ventilation filters with hme

SKU: MP33885

Electrostatic bacterial and viral filters with heat and moisture element to effectively warm and moisten the air while also

protecting the patient and healthcare workers from airborne microbes.
Features

  • Individually packed and ready to use
  • – Long lasting HME – beyond 24 hours
  • – Ideal humidification performance – avoids excessive

    breathing gas humidification

  • – Designed for breathing circuits and devices
  • – Lightweight – Low tractive force on connection

    – Biocompatible material

  • – Transparent casing – allows easy inspection of blockages
  • – Low dead space – minimizes threat of rebreathing
  • – High quality filtration media with proven efficiency
  • – Low flow resistance
  • – ISO connectors
    • SKU: MP33885 Categories: , Tags: ,
    Technical parameters  Adult (Code: 2130)  Paediatric (Code: 2230)
     Filtration efficiency (Bacterial and Viral)   >99.999%   >99.999%
     Mode of filtration   electrostatic   electrostatic
     Humidity output  34 mg/l @VT-500ml   34 mg/l @VT-250ml
     Tidal volume   250-1000 ml   75-250 ml
     Flow resistance   <0.3kpa @60 LPM   <0.2kpa @20 LPM
     Dead space   <45 ml   <20 ml
     Connectors    22M/15F, 15M/22F  15F/22M, 15M
     Weight  <30g    <20g
     Luer lock port for CO2 sampling   Yes   Yes
