California-FA

Product Information

California Has Three Versions Available To Be Customizable For Use In Multiple Eyecare Settings And The New Hardware And Software Technology Will Enable Practitioners To See More, Discover More And Effectively Treat More Ocular Pathology Thus Promoting Patient Health.

Product Description

California has three versions available to be customizable for use in multiple eyecare settings and the new hardware and software technology will enable practitioners to see more, discover more and effectively treat more ocular pathology thus promoting patient health.

California fa image modalities and image viewing options:

Image Modalities

– Color

– Red-free

– Choroidal

– Autofluoresence

– Fluorescein angiography

Image Views

– Standard: 200⁰ Single Capture

– Auto-montage: Up to 220⁰ (not available for FA)

– Central Pole: Detailed view of the macula

– Stereo: Image pairing for optic disc and retinal evaluation

Technical Specifications

Image Modalities:

optomap color and optomap plus (red and green laser):

Color composite view

Green laser view

Red laser view

optomap af (green laser): autofluorescence

optomap fa (blue laser): fluorescein angiography

Resolution

optomap color: 20 μm

optomap plus, af, fa: 14 μm

Wavelengths

Red laser: 635 nm

Green laser: 532 nm

Blue laser: 488 nm

Exposure Time:

Less than 0.4 seconds

Footprint

Width: 550 mm / 22 inches

Depth: 550 mm / 22 inches including chinrest

Height: 608-632 mm / 24-25 inches

Weight

34 kg/ 75 lbs

Laser Class

Laser safety Class-1 following IEC/EN60825-1:2007

and 21 CFR1040.10 and 1040.11

System Voltage

US: 100-120V at 50/60Hz

EU/AU: 200-240V at 50-60Hz

Power Consumption

Max. 300 VA

Communication Protocol

DICOM Compatible
